SRT W35 SERVO 35KG – 0.10 AT 8.4V SRT-W35

KEY FEATURES

• Ideal for 1/10 on road and 1/8 off road scale applications
• Intermediate aluminum case
• NMB dual main bearings
• Superior waterproof
• 25T output shaft
• 1-Year Limited Warranty

PRODUCT SPECIFICATIONS

• Type: Digital
• Bearing: Dual
• Motor Type: Coreless
• Gear Type: Metal
• Gear Material: Titanium & Steel
• control system: pulse width control
• working frequence: 1520μs / 330hz
• operating voltage: dc6.0-8.4v
• operating temperature range: -10 to + 60 degree
• operating speed (6.0v): 0.15 sec/60 degrees at no load
• operating speed (7.4v): 0.12 sec/60 degrees at no load
• operating speed (8.4v): 0.10 sec/60 degrees at no load
• stall torque (6.0v): 25.0kg.cm (347.2 oz/in)
• stall torque (7.4v): 30.0kg.cm (416.6 oz/in)
• stall torque (8.4v): 35.0kg.cm (486.1 oz/in)
• potentiometer drive: direct drive
• dimensions: 40.7×20.5×38.6 mm /1.60×0.81×1.52 in
• weight: 82.5g (2.91 oz)
• connector wire length: jr 360 mm
